Complete Precision CNC Flybarless Head System for Outrage G5 T Rex 450 3DX450 others
Flybarless head system provides 15% more power and less parts for Outrage G5 helicopters and T-REX 450 helicopters
Drop in replacement for all 450 size helicopters T Rex 450 & 3DX450 plus Super Hero etc Fits Outrage G5 check our prices compared to Outrage prices !!
Precision CNC aluminum with cool black anodizing colors
High quality bearings
Includes
- CNC aluminum Main Blade grips
- CNC aluminum Center Hub
- Fiber Swashplate DriveCNC aluminum washout base and arms
- CNC aluminum swashplate
- New linkages rods
- Hardened spindle shaft and main shaft
Can be used with the GAUI Flybarless E-Stabilizer GU-365 for complete control.
Note we have fitted this Flybarless head with very little modification to our Mini Titan E325 with sucess.
Instructions in RAR Zip File will ship after purchase of head
find out more
Skookum SK360 Cyclic Gyro-Stabilizer Flybarless System with USB
Overview
Throw out your "1940s-technology" mechanical flybar and replace it with a state of the art Digital Flybar. Rock solid hovering with a less complex, lighter rotorhead for more power or longer flight times!
The SK-360 Digital Flybar is a high performance, compact and lightweight electronic pitch and roll stabilizer for model helicopters of all sizes. Its function is to replace the traditional flybar (stabilizer bar) and its association linkages, boosting power, increasing flight times and reducing repair costs.
For 3D flying, dial up cyclic rates to the limit of blade stall, without losing any stability. This gives your heli lightning-quick 3D, with great performance in wind and a solid hover!
For Scale flying, cyclic rates can be dialed down for smooth, steady flight even in gusty wind. Both the look and the sound are more realistic. The SK360 flies great with 2, 3, 4, or 5 blades.
The SK-360 is a compact, single unit, and comes with a USB interface included. It weighs only 16 grams, and can be mounted upside-down, backwards, or rotated 90 degrees to fit in any heli.
The PC setup software lets you fully configure the swash mixing, servo motion, and stability. And, it's easy to upgrade the firmware at home so you'll benefit from any future product improvements with the click of your mouse. Plus, the setup software displays the precision PWM inputs and outputs, making it an excellent calibration tool for your servos and radio.
(Note: For nitro helis, the SK360 has now been tested up to 90 size)
Control Options:
· Adjustable Bell and Hiller ratio (direct vs. stabilized control)
· Adjustable roll (aileron) and pitch (elevator) rates
· Control feel is adjustable in-flight with optional Bank Switching & gain channel
Swashplate Options:
· Works with Digital or Analog servos
· Suitable for 120, 135/140, and 90 degree eCCPM, as well as mCCPM swashplates
· Swash Ring anti-binding algorithm
· Phase Trim adjustable to +-90°
· Swash servo-equalizing prevents uncommanded collective in aggressive maneuvers
High Performance:
· Synchronous, 12-bit precision (4096 step) PWM inputs from your radio
· Tightly grouped 12-bit servo PWM outputs for low swash motion error
· Super-accurate, crystal driven PWM timing
· Optional 125 Hz Digital servo frame rate
· Minimal lag (just a few milliseconds)
· Individually temperature compensated
· Wide input voltage range (up to 8.5 volts)
· Weight is only 16 grams
Package Contents:
· SK-360 Gyro unit
· Four receiver connection cables
· Four strips of 3M-4408tm mounting tape
· USB Interface with jumper
· USB Extension Cable
· CD with Interface Software
SK360 - Technical Specifications
Dimensions: 41 x 31 x 15 mm (1.6 x 1.2 x 0.6 in)
Weight (without cables): 16 grams (0.5 oz)
Operating Temp. Range: -5c to +45c
Operating Voltage: 3.6 to 8.5 VDC
Power Consumption: 28mA
Wiring Gauge: 22 or 24
Input Signals: 3-4 Channels (PWM 700-2300 us)
Servo Options: Analogue or Digital
Setup: USB interface, or by Transmitter Sticks
Field Gain Settings: Bell and Hiller Gain Dials, 0 - 100%
find out more
MAXPRO Battery Detector LCD 1 to 6S monitor
Use for RC Model Batterys voltage Diagnosis and measurement
Check the extended information for a copy of the checker instructions in full
Features
1. For RC model battery diagnosis and measurement use.
2. High precision display of unit cell voltage for 1 to 6s Lithium packs, it also displays total pack voltage and the percentage of pack remaning capacity.
3. Big LCD screen can display up to 6cells unit voltage & total voltage clearly & directly.
4. Timer mode can count the flying time
5. LED can remind the user once unit cell voltage drop to 3.70V.
6. Reverse polarity protection for cell input
Spectifications
1. Voltage measurement range: 1~6s Lipo/Li-ion/LiMn
2. Voltage display resolution: 0.01V.
3. Voltage detection precision: 0.5%
4. Unit voltage display range: 3.00~4.99V, Total voltage display range: 3.00~29.99V
5. Time display resolution: 1 second
6. Time display range: 0:00~29:59
7. Size: 60x35x6mm, Weight: 20g
find out more
HeliArtist Mini 500D Army Fiber Glass Fuselage HA200HU002
Product features
HeliArtist Mini 500D Army fuselage use for
ALIGN T-REX 250/Gaui EP200 /Esky Lama
Specification:
*Body length:415mm
*Body width:95mm
*Body high:162mm
*Weight :139g
Accessory:
*Fiber Glass scale fuselage x 1
*Pellucid canopy cover x 1
*Horizontal stabilizer x 1
*Vertical stabilizer x 3
*Fiber Glass Landing Gear x 4
*Aluminum Skids x 2
*Frame Stand Wood Board 1
*Frame Stand Wood pack x 1
*Screw Pack x1
*Window cover x4
find out more
UGL-42 Auto Rotation Case W Bearing 3DX 500
UGL-42 Auto Rotation Case W Bearing 3DX 500
find out more
HeliArtist 450 BO105 Fiber Glass Fuselage(Police)
Product features]:
use for
ALIGN T-REX450X/XL/SE/SE V2/Sport
Specification:
*Body length: 730mm
*Body width: 136mm
*Body high: 215mm
*Body weigh: 347g
Accessory:
*Fiber Glass scale fuselage x 1
*Pellucid canopy cover x 1
*Horizontal stabilizer x 2
*Upper Tail Assembly Set x 1
*Belt x 1
*Landing Gear Set x 1 Pack
*Frame Stand Wood x 1 Pack
*Screw Pack x 1
find out more
Silver Carbon UGL-SA16 Battery Trays
Silver Carbon UGL-SA16 Battery Tray.
Fits SAH and SAS type frame in picture of frame above
find out more
METAL CASE G401B Version NEW Product
Same Features as Plastic Case G401B but with metal case for added crash protection.
Comes with instructions
find out more
ALIGN 500 3G Programmable Flybarless System Combo/Black
ALIGN 500 3G Programmable Flybarless System Combo/Black
Specifications:
Suitable Voltage Range:DC 4.5~8.4V
Current Comsumption:DC11.1-22.2V 3-6cell Li-Po
Flip and Roll rate detection speed: :±300degrees/sec
Rudder rate detection speed:±500degrees/sec
Sensor resolution:12bit
Operating temperatur:-20?~65?
Operating humidity:0%~95%
RoHS certified
Dimension: Control box:42x26.5x14.5mm Sensor:22.3x21.7x14mm
Weight: Control box:16g Sensor:9g
Instructions:
3-axis gyroscopic flybarless system to simulate the stability of mechanical flybar system, yet at the same time achieving agile 3D performance.
Utilizes Silicon Micro Machine (SMM) sensors for excellent stability.
12 bit processors providing ultra high resolution, resulting in highly precise controls
Software upgradable through PC interface adapter (sold separately)
Simplistic setup process without the need of external devices. Setup is done through 5 steps and 2 sensitivity adjustments. Rudder setup is identical to GP780 gyro, minimizing learning curve.
Flybarless system dramatically improves 3D power output and efficiency, resulting in reduced fuel or electricity consumption.
Highly sensitive gyroscopic sensors combined with advanced control detection routine providing higher hovering and aerobatic stability than other flybarless system.
Suitable for all CCPM and mechanical mixing system.Comaptible with helicopter of all sizes from T-Rex 250 to T-Rex 700.
Innovative Pitch Gau as an aid to facilitate pitch adjustments.
High frame rate signal output for faster and higher precision servo response.
Capable to operate between 4.5V to 8.4V, compatible with high voltage servos.
Small footprint, light weight, minimalists and reliable design.
Accessories:
Main Rotor head Set x1
Flybarless control unit x1
Flybarless Sensor x1
Screw bag x1
Linkage rod A x2
Linkage ball A x2
Head Stopper x1
Mixing base assembly x1
Pitch Gauge x1
Signal extension wire 100mm x1
Signal extension wire 220mm x1
Sensor mounting foam x2
Included
425D Carbon Fiber Blades x1
PRE ORDER
find out more
Skookum SK360 Cyclic Gyro-Stabilizer Flybarless System with USB
Overview
Throw out your "1940s-technology" mechanical flybar and replace it with a state of the art Digital Flybar. Rock solid hovering with a less complex, lighter rotorhead for more power or longer flight times!
The SK-360 Digital Flybar is a high performance, compact and lightweight electronic pitch and roll stabilizer for model helicopters of all sizes. Its function is to replace the traditional flybar (stabilizer bar) and its association linkages, boosting power, increasing flight times and reducing repair costs.
For 3D flying, dial up cyclic rates to the limit of blade stall, without losing any stability. This gives your heli lightning-quick 3D, with great performance in wind and a solid hover!
For Scale flying, cyclic rates can be dialed down for smooth, steady flight even in gusty wind. Both the look and the sound are more realistic. The SK360 flies great with 2, 3, 4, or 5 blades.
The SK-360 is a compact, single unit, and comes with a USB interface included. It weighs only 16 grams, and can be mounted upside-down, backwards, or rotated 90 degrees to fit in any heli.
The PC setup software lets you fully configure the swash mixing, servo motion, and stability. And, it's easy to upgrade the firmware at home so you'll benefit from any future product improvements with the click of your mouse. Plus, the setup software displays the precision PWM inputs and outputs, making it an excellent calibration tool for your servos and radio.
(Note: For nitro helis, the SK360 has now been tested up to 90 size)
Control Options:
· Adjustable Bell and Hiller ratio (direct vs. stabilized control)
· Adjustable roll (aileron) and pitch (elevator) rates
· Control feel is adjustable in-flight with optional Bank Switching & gain channel
Swashplate Options:
· Works with Digital or Analog servos
· Suitable for 120, 135/140, and 90 degree eCCPM, as well as mCCPM swashplates
· Swash Ring anti-binding algorithm
· Phase Trim adjustable to +-90°
· Swash servo-equalizing prevents uncommanded collective in aggressive maneuvers
High Performance:
· Synchronous, 12-bit precision (4096 step) PWM inputs from your radio
· Tightly grouped 12-bit servo PWM outputs for low swash motion error
· Super-accurate, crystal driven PWM timing
· Optional 125 Hz Digital servo frame rate
· Minimal lag (just a few milliseconds)
· Individually temperature compensated
· Wide input voltage range (up to 8.5 volts)
· Weight is only 16 grams
Package Contents:
· SK-360 Gyro unit
· Four receiver connection cables
· Four strips of 3M-4408tm mounting tape
· USB Interface with jumper
· USB Extension Cable
· CD with Interface Software
SK360 - Technical Specifications
Dimensions: 41 x 31 x 15 mm (1.6 x 1.2 x 0.6 in)
Weight (without cables): 16 grams (0.5 oz)
Operating Temp. Range: -5c to +45c
Operating Voltage: 3.6 to 8.5 VDC
Power Consumption: 28mA
Wiring Gauge: 22 or 24
Input Signals: 3-4 Channels (PWM 700-2300 us)
Servo Options: Analogue or Digital
Setup: USB interface, or by Transmitter Sticks
Field Gain Settings: Bell and Hiller Gain Dials, 0 - 100%
find out more
Align DS620 Digital Servo
Coreless Motor Design for fast speed, high efficiency, and low power consumption.
12 Bits signal resolution for smooth movements.
Fast speed and high torque. High strength titanium alloy gears with high precision and durable structure characteristics.
Aluminum alloy mid case construction for instantaneous heat dissipation, maintaining servos high efficiency.
Supports digital & analog control signal.
Powerful and precise servo, suitable for T-Rex 600/700 swashplate and rudder use and most other 30/90 size machines.
find out more
HeliArtist 450 BO105 Fiber Glass Fuselage(Police)
Product features]:
use for
ALIGN T-REX450X/XL/SE/SE V2/Sport
Specification:
*Body length: 730mm
*Body width: 136mm
*Body high: 215mm
*Body weigh: 347g
Accessory:
*Fiber Glass scale fuselage x 1
*Pellucid canopy cover x 1
*Horizontal stabilizer x 2
*Upper Tail Assembly Set x 1
*Belt x 1
*Landing Gear Set x 1 Pack
*Frame Stand Wood x 1 Pack
*Screw Pack x 1
find out more
DEAO SM -STH5004 Scale 4 blade tail rotor head
SM -STH5004 Scale 4 blade tail rotor head
This premium cnc full 7075 aluminium 4 blades tail rotor head that is perfect for a scale helicopter. Its advanced plug-n-play design requires no extra parts or special timing adjustments.
Makes your scale heli look great and fly well preformance .It is for 500 Align .Bullet -500 or any 5 mm shaft models .The special design for your orginal shaft .
Length : 62 mm (screw centre)
Shaft diameter : 5 mm
weight :44g
Available mid December 2009
find out more
Apache AH-64 A (GREEN)
The Apache AH-64A is the world first 600 size scale attack helicopter .It is designed by computer and precision CNC machines .
This is a highly detailed scale model fuselage.
The kit includes the base weapon set and CNC Steel and Alloy suspension front and rear scale landing gear.
The kit includes a special metal side main frame for Align 600 , Bullet -600 or any clone 600.
Also suitable for Logo-400/10 ,Swift-16 .
The detail front sensor ,dummy machine gun are included
(Hell-Fire rocket set are optional parts )
Factory painted military green colour
Two piece fuselage
TFM-600-4 blades rotor head are perfect match for this model we sell these also from Sportsmoto
Length:1450 mm
width:360 mm
High:500 mm
Flying weight :10 lb
find out more
Laser guided level various uses
This laser level guide will have you cutting the straightest lines in the universe, plus enable you to build the squarest tail pieces ever known to man.
Specifications:
Dimensions: 123 x 63 x 40mm
Laser wavelength: 625~670nm
Power: 2 x AAA batteries (Not included)
Complies with 21CFR 1040.10 and 1040.11
find out more
Button spirit level 2 pcs
Excellent for flat surface leveling.
Includes 2 spirit level buttons.
Size: 25 x 9mm
Weight: 3.3g
SUPER TIP
We use it on our heli's equipped with Flymentor & Alien Command to level the heli before switching the power on.
find out more
Extreme 3700 3S 11.1v 35C
Product Use: Extreme 3700 3S 11.1v 35C
Product Configuration: 3S
Product Charge Rate: 2C
Product Discharge Rate: 35C
Ask a question about this product
--------------------------------------------------------------------------------
Overlander Extreme 35C 3700mAh 11.1v Lipoly. Awesome power This pack delivers power to the motor without any loss in voltage Described in review as a 'new baseline against which to measure lipo performance'.
find out more
Overlander Extreme 35C 4400mAh 22.2v Lipoly
Overlander Extreme 35C 4400mAh 22.2v Lipoly
Size: Overlander Extreme 35C 4400mAh 22.2v Lipoly
Dimensions 52mm x 46 mm x 160 mm
Unit Weight: 735 gms
Use: N/A
Configuration: 1
Charge: 4.4
Discharge: 154
find out more
Tel 0843 289 9681
| ||
![]() Heli Artist EC 135 Fan System NEWNEW product HeliArtist EC135 CNC Fan System V2 Clicxk to see the product | ||
![]() T Rex 450 Pro Canopys from SonixNew for December 2009 T Rex 450 Pro aftermarket Canopy. Great New colours and styles | ||
![]() In STOCK Flymentor 3DNew type of sensing process provides reliable geographical positioning, completely independent of the visible horizon. This a brand new Product only Just released August 2009. attractive pricing for a lot of technology! Read More about this products launch | ||
![]() Alien Command Advanced Product £120.00 Plus ShippingAlien Command Advanced | ||
![]() DEAO Head systems for 450 size scale HelicoptersNew products from Sportsmoto Ltd the DEAO 450 size scale helicopter head system fits most common 450 size helicopters with a 5mm main shaft. 3,4,5 blade head system available | ||
![]() NEW Blade 400 Frame Options Check them out..Following on from the huge success of our Blade 400 Frame sets in G10 comes the Carbon Fibre options in Silver weave and Black weave. | ||
![]() Heli Artist Fuselages great Winter Projectsclick to see 450 / 500 size Heli Artist Fuselages now with Fan unit options.. | ||
![]() Airwolf 450 V3 Heli Artist Back in Stock for that Winter ProjectIt's back the Airwolf 450 Fuselage just in time for Xmas. | ||
![]() NEW 2010 PRODUCTS Hitec Radio EquipmentDue to our increased expansion we are now offering a greater range of products including Hitec Radio systems. we will be expanding the Hitec product range over the coming weeks. Click to see radio range | ||
![]()
| ||
![]() FREE Tips Going Flybarless on a Budget !We recently took a lead from Dennis Stretton at Model Helicopter World Magazine who recently reviewed the LF Technik Sportsmoto supplied Gyrobot 900 for us Sept Issue. | ||
![]() SONIX SX 450 SE Available NowNOW In Stock the SX 450 SE Helicopter. | ||
![]() Check out the 3DX450 Range of Helicopters from Sportsmoto 2009 V4 versions in stockOur Best seller by far the 3DX450B Helicopter from SONIX | ||
![]() FLYCAM L4500 Mount For 400, 450 & 500 Size HelicoptersFLYCAM Artist L4500 lightest complete camera mount 180g only. | ||
| ||
![]() Gaui Hurricane EP200SEV2 + ESC + MotorThe only and the best 3D capable micro helicopter reduces the 3D flying cost (Even 7.4V/2S1P/LiPo battery can provide the most powerful maneuver than other helicopters which use 11.1V/3S1P/LiPo battery in this class). | ||
![]() Sportsmoto Ltd UK dealers in LF Technik Products | ||
![]() Sportsmoto Ltd agrees to be a Sundog Model Glasses DealerREAD ABOUT SUNDOG GLASSES FOR MODEL FLYING | ||
![]() T REX 250 SPARES NOW AVAILABLECheck out our cost saving crash parts for the T Rex 250 Helicopter. Main shafts, Feathering spindles, flybar rods , main blades, all lower cost than genuine Align. made by SONIX great quality as always and lower cost flying. CLICK HERE TO SEE THE T REX 250 SPARES ALSO NOW T REX 250 SILVER CARBON FRAME SETS !!! | ||
![]() Make sure you subscribe FREE to Helista Helicopter MagPut this on your 10 things to do before you die !! FREE and very good the online NEW magazine from Helista. | ||
| ||
![]() Overlander 35C Extreme Battery's As Seen in Helicopter WorldCheck these NEW range of 35C batterys for 11.1 V - 14.8 V & 22.2 V from mini helis like the Align T Rex 250 or Gaui 200 Helicopters up to T Rex 600 size helicopters, these batterys offer superb performance. Overlander ESC range recently added to web site | ||
![]() Honey Bee King 2 K2 SX Head Upgrade NEW 2009Check out the NEW SX K2 CNC Head upgrade for the King 2 Honey Bee , includes the correct swashplate for the conversion. | ||
Our Ebay RatingIt's over 2,055 satisfied trades with a 99.6% rating...29-12-09 | ||
![]() Thunder Tiger Mini Titan Upgrades in CNC alloy
| ||
![]() T Rex 600 & 500 CNC Upgrade Parts Great Value OfferT Rex 600 CNC upgrade parts for your T Rex Helicopter. Order a combo to save on buying individually..Buy On Line Now these are now available in black and matt alloy finish | ||
![]() Tools to help you set up a great flying helicopter are essentialOur Carbon Fibre and CNC alloy Blade Balancer is just the ticket for setting up 400/450 and some 500 helicopter main blades. | ||
Payments by Pay Pal account or Credit CardYou can easily pay for your goods online with Pay Pal. Either by having a Pay Pal account or using the option of credit card via Pay Pal. Get a Pay Pal Account Now Pay Pal accepts VISA Mastercard, American Express all very easy to use and buy online | ||
![]() Tail assembly Compatable T Rex Parts availableCheck out the quality of the CNC machined parts for the T Rex and 3DX 450 compatable spares |
UGL-63 Drive Belt Lepton 3DX 500 583T UGL-63 Drive Belt Lepton 3DX 500 | Complete Precision CNC Flybarless Head System for Outrage G5 T Rex 450 3DX450 others Flybarless head system provides 15% more power and less parts for Outrage G5 helicopters and T-REX 450 helicopters | Skookum SK360 Cyclic Gyro-Stabilizer Flybarless System with USB Overview | ||
MAXPRO Battery Detector LCD 1 to 6S monitor Use for RC Model Batterys voltage Diagnosis and measurement | HeliArtist Mini 500D Army Fiber Glass Fuselage HA200HU002 Product features | UGL-39 Auto Rotation Sleeve 3DX 500 UGL-39 Auto Rotation Sleeve 3DX 500 | ||
UGL-42 Auto Rotation Case W Bearing 3DX 500 UGL-42 Auto Rotation Case W Bearing 3DX 500 | HeliArtist 450 BO105 Fiber Glass Fuselage(Police) Product features]: | UGL-51 Rod End Set 3DX500 UGL-51 Rod End Set 3DX500 | ||
Silver Carbon UGL-SA16 Battery Trays Silver Carbon UGL-SA16 Battery Tray. | ||||
METAL CASE G401B Version NEW Product Same Features as Plastic Case G401B but with metal case for added crash protection. | ALIGN 500 3G Programmable Flybarless System Combo/Black ALIGN 500 3G Programmable Flybarless System Combo/Black | Skookum SK360 Cyclic Gyro-Stabilizer Flybarless System with USB Overview | ||
Align DS620 Digital Servo Coreless Motor Design for fast speed, high efficiency, and low power consumption. | HeliArtist 450 BO105 Fiber Glass Fuselage(Police) Product features]: | DEAO SM -STH5004 Scale 4 blade tail rotor head SM -STH5004 Scale 4 blade tail rotor head | ||
Apache AH-64 A (GREEN) The Apache AH-64A is the world first 600 size scale attack helicopter .It is designed by computer and precision CNC machines . | Laser guided level various uses This laser level guide will have you cutting the straightest lines in the universe, plus enable you to build the squarest tail pieces ever known to man. | HFT920 AURORA 9 2.4GHZ + 9CH RX + SERVOS | ||
Button spirit level 2 pcs Excellent for flat surface leveling. | Extreme 3700 3S 11.1v 35C Product Use: Extreme 3700 3S 11.1v 35C | Overlander Extreme 35C 4400mAh 22.2v Lipoly Overlander Extreme 35C 4400mAh 22.2v Lipoly | ||
Sportsmoto Ltd Company Number 6709642 Ltd in United Kingdom
